Same model may have multiple batches, images only for reference.

IRFP3415PBF

Name: IRFP3415PBF
Brand: Infineon Technologies
SKU: 605098
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRFP3415PBF
Manufacturer	Infineon Technologies
Catalog	FETs - Single
Description	HEXFET® Power MOSFET \| MOSFET N-CH 150V 43A TO-247AC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Bulk
Transistor Polarity	N-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	150V
Id - Continuous Drain Current	43A
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Maximum) at Id, Vgs	42mOhm at 22A, 10V
Gate Source Voltage(th) (Maximum) at Id	4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	200nC at 10V
Gate Source Voltage (Maximum)	±20V
Input Capacitance (Ciss) (Maximum) at Vds	2400pF at 25V
Power Dissipation (Maximum)	200W
Temperature Range - Operating	-55°C ~ 175°C
Mounting Style	Through Hole
Supplier Device Package	TO-247AC
Manufacturer Package	TO-247-3
Manufacturer Pack Quantity	400
MSL Level	1 (Unlimited)
Win Source Part Number	1187786-IRFP3415PBF
Manufacturer Homepage	www.irf.com
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian IRFP3415PBF CAD Model

Description

The Infineon Technologies IRFP3415PBF is a N-Channel MOSFET transistor with a drain-source breakdown voltage of 150V, continuous drain current of 43A, and maximum power dissipation of 200W.

Maximum Gate-Source Voltage: ±20V
Gate-Source Voltage Threshold: 4V @ 250μA
Input Capacitance: 2400pF @ 25V
Mounting Style: through-hole
Package: TO-247AC
Drive Voltage: 10V
Temperature Range: -55°C to 175°C
Gate Charge: 200nC @ 10V
Pack Quantity: 400
Popularity: medium
