IRFH5206TRPBF

Name: IRFH5206TRPBF
Brand: Infineon Technologies
SKU: 604922
Availability: InStock
Rating: 4.84 (73 reviews)

Get a Quote

Part No	IRFH5206TRPBF
Manufacturer	Infineon Technologies
Catalog	FETs - Single
Description	HEXFET Power MOSFET \| MOSFET N-CH 60V 16A 8-PQFN
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel
Status	Obsolete
Transistor Polarity	N-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	60V
Id - Continuous Drain Current	16A, 89A
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Maximum) at Id, Vgs	6.7mOhm at 50A, 10V
Gate Source Voltage(th) (Maximum) at Id	4V at 100μA
Gate Charge (Qg) (Maximum) at Vgs	60nC at 10V
Gate Source Voltage (Maximum)	±20V
Input Capacitance (Ciss) (Maximum) at Vds	2490pF at 25V
Power Dissipation (Maximum)	3.6W, 100W
Temperature Range - Operating	-55°C ~ 150°C
Mounting Style	SMD
Supplier Device Package	8-PQFN (5x6)
Manufacturer Package	8-PowerVDFN
Manufacturer Pack Quantity	1
MSL Level	1 (Unlimited)
Win Source Part Number	1187610-IRFH5206TRPBF
Manufacturer Homepage	www.irf.com
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Power Management, Motor Drive & Control
Ultra Librarian 3D Model	Ultra Librarian IRFH5206TRPBF CAD Model

Description

The IRFH5206TRPBF is a N-channel MOSFET transistor manufactured by Infineon Technologies.

Drain-source voltage rating: 60V
Continuous drain current: 16A
Maximum on-resistance: 6.7mOhm @ 50A and 10V gate-source voltage.
Applications: power management, motor drive and control applications.
Package: PowerVDFN-8
Power dissipation: 3.6W.
Supply and demand status: balanced.
