IR2101S Real Image IR2101S real image11728
Same model may have multiple batches, images only for reference.
IR2101S Real Image IR2101S real image11728
IR2101S Real Image IR2101S real image11728
Same model may have multiple batches, images only for reference.

IR2101S

Part No IR2101S
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description HIGH AND LOW SIDE DRIVER | IC DRIVER HIGH/LOW SIDE 8-SOIC
Datasheet
IR2101S Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Tube
Status Obsolete
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 2
Gate Type IGBT, N-Channel MOSFET
Supply Voltage (V) 10V ~ 20V
Logic Voltage - VIL, VIH 0.8V, 3V
Current - Peak Output (Source, Sink) 210mA, 360mA
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 600V
Rise / Fall Time 100ns, 50ns
Temperature Range - Operating -40°C ~ 150°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SOIC
Family Part Number IR2101S
Manufacturer Pack Quantity 95
MSL Level 1 (Unlimited)
Win Source Part Number 1186529-IR2101S
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IR2101S CAD Model

Description

The IR2101S is an integrated circuit manufactured by Infineon Technologies.

  • Category: Integrated Circuits
  • Popularity: Medium
  • Type: Half-bridge gate driver IC
  • Designed to drive: IGBTs and N-channel MOSFETs
  • Channels: Two independent channels
  • Input Type: Non-inverting
  • Gate Type: IGBT and N-channel MOSFET
  • Logic Voltage - VIL, VIH: 0.8V, 3V
  • Current - Peak Output (Source, Sink): 210mA, 360mA
  • High Side Voltage - Max (Bootstrap): 600V
  • Ideal for: Use in various electronic devices that require high-speed switching and efficient power conversion.
