IR2086S Infineon Technologies IR2086S real image
Same model may have multiple batches, images only for reference.
IR2086S Infineon Technologies IR2086S real image
IR2086S Infineon Technologies IR2086S real image
Same model may have multiple batches, images only for reference.

IR2086S

Part No IR2086S
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description IC DRIVER FULL BRIDGE 16-SOIC
Datasheet
IR2086S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Synchronous
Number of Drivers 4
Gate Type N-Channel MOSFET
Supply Voltage - Operating 9.5 V to 15 V
Current - Peak Output (Source, Sink) 1.2A, 1.2A
Input Type RC Input Circuit
High Side Voltage - Max (Bootstrap) 100V
Rise and Fall Time 40ns, 20ns
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 090623-IR2086S
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IR2086S CAD Model

Description

The Infineon Technologies IR2086S is a synchronous channel type voltage regulator controller with an RC input circuit.

  • Driven Configurations: Half-bridge
  • Drivers: Four drivers with N-Channel MOSFET gate type
  • Peak Output Current: 1.2A
  • High Side Voltage: Maximum of 100V with bootstrap
  • Package: 16-SOIC
  • Supply Voltage Range: 9.5V to 15V
  • Rise Time: 40ns
  • Fall Time: 20ns
  • Operating Temperature Range: -40°C to 125°C
  • Supply and Demand Status: Limited
