IKW50N60DTPXKSA1 Infineon Technologies
Same model may have multiple batches, images only for reference.

IKW50N60DTPXKSA1

Part No IKW50N60DTPXKSA1
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT TRENCH/FS 600V 80A TO247-3 / IGBT Trench Field Stop 600 V 80 A 319.2 W Through Hole PG-TO247-3
Datasheet
IKW50N60DTPXKSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - IGBTs - Single
Mfr Infineon Technologies
Series TrenchStop™
Package Tube
Product Status Not For New Designs
IGBT Type Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) 600 V
Current - Collector (Ic) (Max) 80 A
Current - Collector Pulsed (Icm) 150 A
Vce(on) (Max) @ Vge, Ic 1.8V @ 15V, 50A
Power - Max 319.2 W
Switching Energy 1.53mJ (on), 850µJ (off)
Input Type Standard
Gate Charge 249 nC
Td (on/off) @ 25°C 20ns/215ns
Test Condition 400V, 50A, 7Ohm, 15V
Reverse Recovery Time (trr) 115 ns
Temperature Range - Operating -40°C ~ 175°C (TJ)
Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package PG-TO247-3
Base Product Number IKW50N60
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Names SP001379678,2156-IKW50N60DTPXKSA1,INFINFIKW50N60DTPXKSA1
Standard Package 30
Win Source Part Number 1217897-IKW50N60DTPXKSA1
Ultra Librarian 3D Model Ultra Librarian IKW50N60DTPXKSA1 CAD Model

Description

The Infineon Technologies IGBT single transistor IKW50N60DTPXKSA1 is a high-power device designed for use in various electronic systems manufactured by Infineon Technologies.

  • Win Source Part Number: 1217897
  • Category: Discrete Semiconductor Products
  • Package: TO-247-3
  • Maximum Power: 319.2W
  • Maximum Current: 80A
