IKW40N60H3 Infineon Technologies IKW40N60H3 Real Image IKW40N60H3 real image IKW40N60H3 label picture
Same model may have multiple batches, images only for reference.
IKW40N60H3 Infineon Technologies IKW40N60H3 Real Image IKW40N60H3 real image IKW40N60H3 label picture
IKW40N60H3 Infineon Technologies IKW40N60H3 Real Image IKW40N60H3 real image IKW40N60H3 label picture
Same model may have multiple batches, images only for reference.

IKW40N60H3

Part No IKW40N60H3
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description Trans IGBT Chip N-CH 600V 80A 306000mW Automotive 3-Pin(3+Tab) TO-247 Tube / IGBT 600V 80A 306W TO247-3
Datasheet
IKW40N60H3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
IGBT Type Trench Field Stop
VCEO Maximum Collector-Emitter Breakdown Voltage 600V
Maximum Current Collector 80A
Pulsed Collector Current 160A
Collector-emitter saturation voltage(Max) 2.4V @ 15V, 40A
Maximum Power Dissipation 306W
Total Switching Energy(Ets) 1.68mJ
Input Type Standard
Gate Charge 223nC
Turn-on and Turn-off delay time 19ns/197ns
Testing Conditions 400V, 40A, 7.9 Ohm, 15V
Reverse Recovery Time (trr) 124ns
Temperature Range - Operating -40°C to 175°C (TJ)
Mounting Through Hole
Case / Package PG-TO247-3
Win Source Part Number 068793-IKW40N60H3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name IKW40N60H3
Introduction Date June 14, 2010
ECCN EAR99
Country of Origin China , Philippines
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IKW40N60H3 CAD Model

Description

The Infineon Technologies IKW40N60H3 is a powerful and efficient trench field stop IGBT that is perfect for use in a variety of applications.

  • Maximum Current Collector: 80A
  • VCEO Maximum Collector-Emitter Breakdown Voltage: 600V
  • Maximum Power Dissipation: 306W
  • Pulsed Collector Current: 160A
  • Collector-Emitter Saturation Voltage (max): 2.4V @ 15V, 40A
  • Total Switching Energy (Ets): 1.68mJ
  • Package: PG-TO247-3
  • Temperature Range: -40°C to 175°C (TJ)
