IGW30N100TFKSA1 Infineon Technologies
Same model may have multiple batches, images only for reference.

IGW30N100TFKSA1

Part No IGW30N100TFKSA1
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT 1000V 60A 412W TO247-3
Datasheet
IGW30N100TFKSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
IGBT Type Trench Field Stop
VCEO Maximum Collector-Emitter Breakdown Voltage 1000V
Maximum Current Collector 60A
Pulsed Collector Current 90A
Collector-emitter saturation voltage(Max) 1.9V @ 15V, 30A
Maximum Power Dissipation 412W
Total Switching Energy(Ets) 3.8mJ
Input Type Standard
Gate Charge 217nC
Turn-on and Turn-off delay time 33ns/535ns
Testing Conditions 600V, 30A, 16 Ohm, 15V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package PG-TO247-3
Win Source Part Number 1045147-IGW30N100TFKSA1
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IGW30N100TFKSA1 CAD Model

Description

The Infineon Technologies 1045147-IGW30N100TFKSA1 is a high-performance IGBT transistor designed for use in various applications.

  • Component Mounting: Through Hole
  • Series: Trench Field Stop IGBT
  • Voltage - Collector Emitter Breakdown Max: 1000 V
  • Current - Collector (Ic) (Max): 60 A
  • Power - Max: 412 W
  • IGBT Type: Standard
  • Gate Charge: 217 nC
  • Vce(on) (Max) @ Vge, Ic: 1.9 V @ 15 V, 30 A
  • Total Switching Energy: 3.8 mJ
  • Turn On Delay Time: 33 ns
  • Turn Off Delay Time: 535 ns
  • Test Condition: 600V, 30A, 16 Ohm, 15V
