BSP452HUMA1 Real Image BSP452HUMA1 Real Image1 BSP452HUMA1 Real Image2 BSP452HUMA1 Real Image3 BSP452HUMA1 Real Image4 BSP452HUMA1 Real Image5
Same model may have multiple batches, images only for reference.
BSP452HUMA1 Real Image BSP452HUMA1 Real Image1 BSP452HUMA1 Real Image2 BSP452HUMA1 Real Image3 BSP452HUMA1 Real Image4 BSP452HUMA1 Real Image5
BSP452HUMA1 Real Image BSP452HUMA1 Real Image1 BSP452HUMA1 Real Image2 BSP452HUMA1 Real Image3 BSP452HUMA1 Real Image4 BSP452HUMA1 Real Image5
Same model may have multiple batches, images only for reference.

BSP452HUMA1

Part No BSP452HUMA1
Manufacturer Infineon Technologies
Catalog PMIC - Power Distribution Switches, Load Drivers
Description IC SWITCH POWER HISIDE SOT223-4
Datasheet
BSP452HUMA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type N-Channel
Voltage - Load 5 V to 34 V
Supply Voltage - Operating Not Required
Current - Output (Max) 700mA
Rds On (Typ) 160 mOhm
Input Type Non-Inverting
Fault Protection Current Limiting (Fixed), Over Temperature, Over Voltage
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package PG-SOT223-4
Win Source Part Number 108567-BSP452HUMA1
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BSP452HUMA1 CAD Model

Description

BSP452HUMA1 Description

The BSP452HUMA1 is a high-performance MOSFET designed for precision switching tasks. It excels in energy-efficient applications due to its low inherent resistance and swift response time.

Applications

  • DC-DC converters
  • Load switches
  • Electronic toys

Features and Benefits

  • Impressive switching speed
  • Energy-efficient operation
  • Excellent thermal conductivity
  • Compact and reliable package

Additional Details

Its design prioritizes low energy loss and durability, making it a top choice for developers focusing on long-term efficiency.
