BAS16-02W E6327 Infineon Technologies BAS16-02W E6327 Real Image BAS16-02W E6327 label picture 2 BAS16-02W E6327 label picture 3
Same model may have multiple batches, images only for reference.
BAS16-02W E6327 Infineon Technologies BAS16-02W E6327 Real Image BAS16-02W E6327 label picture 2 BAS16-02W E6327 label picture 3
BAS16-02W E6327 Infineon Technologies BAS16-02W E6327 Real Image BAS16-02W E6327 label picture 2 BAS16-02W E6327 label picture 3
Same model may have multiple batches, images only for reference.

BAS16-02W E6327

Part No BAS16-02W E6327
Manufacturer Infineon Technologies
Catalog Diodes, Rectifiers - Single
Description Rectifier Diode Switching 85V 0.2A 4ns Automotive 2-Pin SCD-80 T/R / DIODE GEN PURP 80V 200MA SCD80-2
Datasheet
BAS16-02W E6327 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Obsolete(EOL)
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 80V
Current - Average Rectified (Io) 200mA (DC)
Voltage - Forward (Vf) (Max) @ If 1.25V @ 150mA
Reverse Recovery Time (trr) 4ns
Current - Reverse Leakage @ Vr 1μA @ 75V
Capacitance @ Vr, F 2pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package PG-SCD80-2
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 200330-BAS16-02W E6327
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name BAS1602W
Introduction Date December 04, 2003
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian BAS16-02W E6327 CAD Model

Description

BAS16-02W E6327 - High-Speed Switching Diode

The BAS16-02W E6327 offers improved high-speed switching capabilities, suitable for various applications that demand reliability and efficiency.

  • Applications/Projects:
    • Data Line Protection
    • Fast Pulsed Logic Circuits
    • High-Speed Data Communication
  • Features and Benefits:
    • Highly Efficient SOD-323 Package
    • Fast Recovery Time
    • Low Leakage Current
  • Additional Details:

    Manufactured to meet stringent quality standards, suitable for automotive and industrial applications.
