The ILX3232DT is a 3V to 5.5V low-power, dual channel RS-232 transceiver from IK Semicon. This device meets the EIA/TIA-232 and V.28/V.24 communication standards, making it suitable for various data communication applications. It uses a minimal number of external components and operates at data rates up to 250 kbps, making it efficient and reliable for serial communication.

Applications:

• Notebook and desktop computers
• PDAs and handheld devices
• Cellular phones
• Printers and peripherals
• Embedded systems with serial communication requirements

Features:

• Dual RS-232 transceiver
• Operates from a single 3V to 5.5V power supply
• Meets EIA/TIA-232 and V.28/V.24 standards
• Data rates up to 250 kbps
• Low power consumption
• Uses small charge pump capacitors

Benefits:

• Provides reliable RS-232 communication interface
• Wide operating voltage range accommodates various systems
• Complies with industry standards
• Supports high data transfer rates
• Extends battery life in portable applications
• Reduces board space and cost

Technical Specifications:

The ILX3232DT requires a single 3V to 5.5V power supply. It features integrated charge pumps that generate the necessary RS-232 voltage levels. The data rate is up to 250 kbps. It typically requires four external 0.1μF capacitors. Detailed specifications including voltage levels, current consumption, and package dimensions can be found in the IK Semicon datasheet.
