Applications:

• Audio amplifiers and preamplifiers
• Active filters
• Instrumentation amplifiers
• Voltage followers
• Signal conditioning circuits

Features:

• Dual operational amplifier in a single package
• High open-loop gain
• Low input noise voltage
• Short circuit protection
• Wide supply voltage range
• No frequency compensation required

Benefits:

• Simplifies circuit design with dual op-amps in one package
• Provides accurate signal amplification due to its high gain
• Ensures clean audio reproduction due to low noise characteristics
• Protects the amplifier from damage due to short circuits
• Adaptable to various voltage requirements
• Easy to implement without external compensation components

Technical Specifications:

The IL4558S-9 operates with a supply voltage range of typically ±5V to ±15V. The common-mode rejection ratio (CMRR) is typically 80 dB. The input bias current is typically 500 nA. Slew rate is around 1.7V/μs. It is available in an SOP-8 package. Further datasheet information from IK Semicon is recommended for precise design parameters.
