The H5TC2G63GFR-PBA is a 2Gb DDR3 SDRAM (Double Data Rate 3 Synchronous Dynamic Random-Access Memory) chip from Hynix Semiconductor. This memory component is designed for applications requiring higher bandwidth and larger memory capacity compared to DDR2. With a capacity of 2 Gigabits (2Gb), it's organized as 128M x 16. DDR3 SDRAM offers improved performance by transferring data at higher clock speeds and with greater efficiency compared to DDR2.

Applications

• PCs and Laptops: As main system memory, providing the necessary bandwidth and capacity for running applications and operating systems.
• Gaming Consoles: Supporting high-resolution textures and complex game environments.
• Graphics Cards: Providing dedicated memory for graphics processing and display.
• Networking Equipment: Used in routers and switches for buffering and processing network traffic.
• Embedded Systems: Providing memory for data storage and processing in various embedded applications.
• High-Definition Televisions (HDTVs): Supporting advanced video processing and display functions.

Features

• 2Gb Capacity: Provides a large amount of memory for demanding applications.
• DDR3 Interface: Offers higher data transfer rates compared to DDR2.
• 128M x 16 Organization: Configured for efficient memory access.
• Operating Frequency up to 800MHz (DDR3-1600): Enables fast data access and processing.
• Double Data Rate: Transfers data on both the rising and falling edges of the clock signal.
• On-Chip DLL (Delay-Locked Loop): Ensures accurate timing and synchronization.
• Write Latency (CWL) of 5, 6, 7, 8, 9, 10: Provides flexible timing options for optimization.
• Power-Saving Features: Reduces power consumption during idle and standby modes.
• Lead-Free Packaging: Complies with environmental regulations.

Benefits

• Increased System Performance: Higher memory bandwidth improves overall system responsiveness and application performance.
• Enhanced Graphics Capabilities: Supports complex textures and rendering effects for improved visual quality.
• Smoother Video Playback: High data transfer rates enable seamless playback of high-resolution video content.
• Reduced Power Consumption: Extends battery life in portable devices and lowers overall energy costs.
• Improved Reliability: Robust design and manufacturing ensure stable operation under various conditions.
• Simplified System Design: Standard DDR3 interface simplifies integration with other system components.

Additional Details

The H5TC2G63GFR-PBA typically operates at a voltage of 1.5V. The PBA suffix likely indicates specific packaging or performance characteristics. It is generally available in a FBGA (Fine-Pitch Ball Grid Array) package designed for surface mount technology. Detailed timing parameters, electrical characteristics, and package dimensions are documented in the product datasheet. This chip complies with JEDEC standards for DDR3 SDRAM. Its speed grade allows for operation at various DDR3 frequencies depending on the system requirements.
