HIF3BA-26PA-2.54DSA(63) Hirose Electric Co Ltd
Same model may have multiple batches, images only for reference.

HIF3BA-26PA-2.54DSA(63)

Part No HIF3BA-26PA-2.54DSA(63)
Manufacturer Hirose Electric Co Ltd
Catalog Rectangular Connectors
Description CONN HEADER VERT 26POS 2.54MM / Connector Header Through Hole 26 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Rectangular Connectors - Headers, Male Pins
Mfr Hirose Electric Co Ltd
Series HIF3B
Package Bulk
Product Status Active
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 26
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole
Termination Solder
Fastening Type Latch Lock/Eject Hooks
Contact Length - Mating -
Contact Length - Post 0.130" (3.30mm)
Overall Contact Length -
Insulation Height 0.701" (17.80mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 8.00µin (0.203µm)
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polybutylene Terephthalate (PBT)
Features Keying Slot
Temperature Range - Operating -55°C ~ 85°C
Ingress Protection -
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) Varies by Wire Gauge
Voltage Rating 200V
Mated Stacking Heights -
Contact Finish Thickness - Post 78.7µin (2.00µm)
Applications -
Base Product Number HIF3
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1378562-HIF3BA-26PA-2.54DSA(63)
Ultra Librarian 3D Model Ultra Librarian HIF3BA-26PA-2.54DSA(63) CAD Model

Description

The Hirose Electric Co Ltd HIF3B series is a range of rectangular connector headers.

  • Style: Header
  • Application: Board to Cable/Wire
  • Temperature Range: -55°C to 85°C
  • Fastening Type: Latch Lock/Eject Hooks
  • Termination: Solder
  • Number of Positions: 26
  • Number of Rows: 2
  • Pitch - Mating: 0.100" (2.54mm)
  • Row Spacing - Mating: 0.100" (2.54mm)
  • Shrouding: Shrouded - 4 Wall
  • Contact Finish: Gold
  • Contact Material: Brass
  • Insulation Material: Polybutylene Terephthalate (PBT)
  • Color: Black
  • Voltage Rating: 200V
  • Product Status: Active
  • Base Product Number: HIF3
