DF50-30DP-1V(51) Real Image
Same model may have multiple batches, images only for reference.

DF50-30DP-1V(51)

Part No DF50-30DP-1V(51)
Manufacturer Hirose Electric Co Ltd
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 30POS 1MM / Connector Header Surface Mount 30 position 0.039" (1.00mm)
Datasheet
DF50-30DP-1V(51) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Hirose Electric Co Ltd
Series DF50
Package Tape & Reel
Connector Type Header
Contact Type Male Blade
Pitch - Mating 0.039" (1.00mm)
Number of Positions 30
Number of Rows 2
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting SMD (SMT)
Termination Solder
Fastening Type Latch Lock
Insulation Height 0.278" (7.06mm)
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 2.00µin (0.051µm)
Contact Finish - Post Gold
Contact Material Brass
Insulation Material Polyester
Features Solder Retention
Temperature Range - Operating -35°C ~ 85°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 1A
Voltage Rating 100V
Mated Stacking Heights 7.35mm
Contact Finish Thickness - Post 2.00µin (0.051µm)
Base Product Number DF50
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names H12051CT,H12051DKR,H12051TR,DF5030DP1V51,665-0001-8-51
Standard Package 1,000
Win Source Part Number 1055381-DF50-30DP-1V(51)
Ultra Librarian 3D Model Ultra Librarian DF50-30DP-1V(51) CAD Model

Description

The DF50-30DP-1V(51) Rectangular Connector - Header, Male Pin is an essential component for electronic devices.

  • Positions: 30
  • Features: Solder retention
  • Fastening Type: Latch lock
  • Voltage Rating: 100V
  • Applications: Computers, consumer electronics, and more
