The DF12B(5.0)-50DP-0.5V(86) is a 50-pin, 0.5mm pitch board-to-board connector manufactured by Hirose Electric Co Ltd. It's part of the DF12 series, known for its space-saving design and reliable connection. These connectors are designed for high-density mounting in various electronic devices.

Applications:

• Mobile phones: Used for connecting internal components.
• Digital cameras: Connects image sensors to the main board.
• Notebook PCs: Used for connecting LCD panels and other internal modules.
• Other compact electronic devices: Suitable for any application requiring small, reliable board-to-board connections.
• Medical equipment: For reliable connections within sensitive devices.

Features:

• 0.5mm pitch: Allows for high-density mounting.
• 50 pins: Provides a large number of connections in a small footprint.
• Board-to-board connector: Designed for connecting two PCBs directly.
• Surface mount technology (SMT): Enables automated assembly.
• Secure locking mechanism: Ensures reliable connection even under vibration.
• Double row contact: Provides good contact reliability.

Benefits:

• Space-saving: Compact design allows for high-density mounting in small devices.
• Reliable connection: Secure locking mechanism and double row contact ensure stable performance.
• Easy assembly: SMT compatibility enables automated assembly, reducing manufacturing costs.
• High signal integrity: Designed to minimize signal loss and interference.
• Durable: Constructed with high-quality materials for long-lasting performance.

Additional Details:

The DF12 series from Hirose is widely used in applications where space is limited and reliable connections are critical. The 0.5mm pitch allows for extremely dense packaging of components. The connector uses a secure locking mechanism to prevent accidental disconnections, and the double-row contact design improves connection reliability. The SMT design allows for easy integration into automated assembly lines.

Technical Specifications:

• Number of Contacts: 50
• Pitch: 0.5mm
• Mounting Type: Surface Mount
• Mating Style: Board-to-Board
• Current Rating: 0.5A
• Voltage Rating: 50V
• Operating Temperature: -30°C to +85°C
• Insulation Resistance: 500 MΩ minimum
• Contact Resistance: 80 mΩ maximum
