M80-5110842 Real Image
Same model may have multiple batches, images only for reference.

M80-5110842

Part No M80-5110842
Manufacturer Harwin Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 8POS 2MM / Connector Header Through Hole 8 position 0.079" (2.00mm)
Datasheet
M80-5110842 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Harwin Inc.
Series Datamate J-Tek
Package Tube
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.079" (2.00mm)
Number of Positions 8
Number of Rows 2
Row Spacing - Mating 0.079" (2.00mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole
Termination Solder
Fastening Type Threaded
Contact Length - Post 0.173" (4.40mm)
Insulation Height 0.220" (5.60mm)
Contact Shape Circular
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 29.5µin (0.75µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Features Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 2.2A
Voltage Rating 800V
Mated Stacking Heights 7.3mm, 7.7mm, 9.75mm, 10.75mm, 13.35mm, 14.75mm
Contact Finish Thickness - Post 118.1µin (3.00µm)
Base Product Number M80-511
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Standard Package 14
Win Source Part Number 1021346-M80-5110842
Ultra Librarian 3D Model Ultra Librarian M80-5110842 CAD Model

Description

The Datamate J-Tek series M80-5110842 is a connector that has 8 positions and is a male pin header.

  • Positions: 8
  • Type: Male pin header
  • Voltage Rating: 800V
  • Connection Type: Board to board or cable
  • Contact Material: Phosphor bronze
  • Insulation Material: Polyphenylene Sulfide (PPS), Glass Filled
  • Contact Finish: Gold
  • Contact Finish Thickness (Mating): 29.5µin (0.75µm)
  • Contact Finish Thickness (Post): 118.1µin (3.00µm)
  • Operating Temperature: -55°C to 125°C
