M80-5011205 Real Image
Same model may have multiple batches, images only for reference.

M80-5011205

Part No M80-5011205
Manufacturer Harwin Inc.
Catalog Circular Connectors - Housings
Description DATAMATE J-TEK DIL MALE VERTICAL / Connector Header Through Hole 12 position 0.079" (2.00mm)
Datasheet
M80-5011205 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Harwin Inc.
Series Datamate J-Tek
Package Tube
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.079" (2.00mm)
Number of Positions 12
Number of Rows 2
Row Spacing - Mating 0.079" (2.00mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole
Termination Solder
Fastening Type Threaded
Contact Length - Post 0.173" (4.40mm)
Insulation Height 0.220" (5.60mm)
Contact Shape Circular
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 29.5µin (0.75µm)
Contact Finish - Post Gold
Contact Material Phosphor Bronze
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Features Keying Slot, Mating Flange
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 2.2A
Voltage Rating 800VAC/DC
Mated Stacking Heights 7.3mm, 7.8mm
Contact Finish Thickness - Post 29.5µin (0.75µm)
Base Product Number M80-501
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Standard Package 12
Win Source Part Number 1143942-M80-5011205
Ultra Librarian 3D Model Ultra Librarian M80-5011205 CAD Model

Description

The M80-5011205 is a 12-position connector that falls under the category of Rectangular Connectors - Headers, Male Pins.

  • Series: Datamate J-Tek
  • Win Source Part Number: 1143942-M80-5011205
  • Manufacturer: Harwin Inc.
  • Standard Package: 12 units
  • Contact Type: Male Pin
  • Termination: Solder
  • Voltage Rating: 800VAC/DC
  • Current Rating: 2.2A
  • Pitch-Mating: 0.079" (2.00mm)
  • Contact Finish-Mating: Gold
