Part No 09061482901
Manufacturer HARTING
Catalog Backplane Connectors
Description CONN DIN HDR 48POS PCB RA / 48 (Power) Position Din Connector Header, Male Pins Through Hole, Right Angle
Datasheet
09061482901 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Backplane Connectors - DIN 41612
Mfr HARTING
Series DIN 41612
Package Bulk
Product Status Active
Connector Type Header, Male Pins
Number of Positions 48 (Power)
Number of Positions Loaded All
Pitch 0.200" (5.08mm)
Number of Rows 3
Style F
Level, Class 1
Mounting Type Through Hole, Right Angle
Termination Solder
Material Flammability Rating UL94 V-0
Material - Insulation Thermoplastic, Glass Filled
Standard Package 20 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 904777-09061482901
Ultra Librarian 3D Model Ultra Librarian 09061482901 CAD Model

Description

The 904777-09061482901 is a DIN 41612 Backplane Connector from HARTING.

  • Connector Type: Header
  • Gender: Male
  • Positions: 48
  • Application: Power
  • Positions Loaded: All Three Rows
  • Pitch: 0.200" (5.08mm)
  • Insulation Material: Thermoplastic, Glass-Filled
  • Flammability Rating: UL94 V-0
  • Mounting Type: Through Hole, Right Angle
  • Package Quantity: 20
  • Manufacturer: HARTING
