1750V

Part No 1750V
Manufacturer Hammond Manufacturing
Catalog Audio Transformers
Description AUDIO XFMR 4KCT / 8, 16 CHAS MNT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Turns Ratio - Primary 15.93:1
Impedance - Primary (Ohms) 4kCT
Impedance - Secondary (Ohms) 8, 16
DC Resistance (DCR) - Primary 138Ohm
DC Resistance (DCR) - Secondary 720mOhm
Transformer Type Push-Pull Audiophile, Ultra-Linear - Tube Output
Frequency Range 70Hz ~ 15kHz
Frequency Response ±1dB
Power Level 30W
Mounting Type Chassis Mount
Size / Dimension 3.125" L x 3.325" W (79.38mm x 84.46mm)
Height - Seated (Max) 3.843" (97.61mm)
Termination Style Wire Leads
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1511006-1750V
Ultra Librarian 3D Model Ultra Librarian 1750V CAD Model
