125ASE

Part No 125ASE
Manufacturer Hammond Manufacturing
Catalog Audio Transformers
Description XFMR 2.5K-10K / 4-32 CHAS MNT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Impedance - Primary (Ohms) 2.5k ~ 10k
Impedance - Secondary (Ohms) 4 ~ 32
DC Resistance (DCR) - Primary 241.7 Ohm
DC Resistance (DCR) - Secondary 229mOhm, 323mOhm, 463mOhm, 670mOhm
Transformer Type General Purpose
Frequency Range 100Hz ~ 15kHz
Frequency Response ±1dB
Voltage - Isolation 1500V @ 1 Second
Power Level 3W
Mounting Type Chassis Mount
Size / Dimension 2.810" L x 1.350" W (71.37mm x 34.29mm)
Height - Seated (Max) 1.690" (42.93mm)
Termination Style Wire Leads
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1510965-125ASE
Ultra Librarian 3D Model Ultra Librarian 125ASE CAD Model

Description
