The 1008C-1R0J is a wire-wound chip inductor manufactured by Frontier Electronics. It's designed for use in various electronic circuits for filtering, impedance matching, and RF applications. The 1008 designation refers to its physical size, with "C" indicating specific dimensional characteristics. The 1R0J denotes its inductance value and tolerance.

Applications

• RF Circuits
• Wireless Communication Devices
• Filters
• Oscillators
• Impedance Matching Networks

Features

• Wire-Wound Construction
• Small Size (1008 Case Size)
• High Q Factor
• Surface Mount Device (SMD)
• RoHS Compliant

Benefits

• Effective filtering and impedance matching
• Compact size for space-constrained applications
• Low losses and high efficiency
• Easy to assemble using automated equipment
• Environmentally friendly

Additional Details

The 1008C-1R0J is a wire-wound inductor, meaning it is constructed by winding a fine wire around a core material. The inductance value is 1.0 μH (microhenry), and the "J" indicates a tolerance of ±5%. The 1008 case size is a standard SMD package, making it compatible with automated assembly equipment. The high Q factor indicates low losses, which is important for maintaining signal integrity in RF circuits. Proper PCB layout is crucial for minimizing parasitic inductance and capacitance, which can affect the performance of the inductor. The inductor should be placed away from other components and traces to minimize interference. Reflow soldering is typically used to attach the inductor to the PCB. Consult the Frontier Electronics datasheet for recommended soldering profiles. The 1008C-1R0J provides a reliable and efficient solution for inductance requirements in a wide range of electronic applications. The core material and wire gauge are selected to optimize performance for specific frequency ranges. The inductor is also shielded to minimize electromagnetic interference (EMI).
