MPX5050GP1

Part No MPX5050GP1
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description PRESSURE SENSOR GAUGE 6-SIP
Datasheet
MPX5050GP1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer NXP
Status Active
Pressure Type Vented Gauge
Operating Pressure 7.25 PSI (50 kPa)
Output Type Analog Voltage
Output 0.2 V to 4.7 V
Accuracy ±2.5%
Supply Voltage - Operating 4.75 V to 5.25 V
Port Size Male - 0.19" (4.93mm) Tube
Port Style Barbed
Features Temperature Compensated
Termination Style PCB
Maximum Pressure 29.01 PSI (200 kPa)
Temperature Range - Operating -40°C to 125°C
Win Source Part Number 138376-MPX5050GP1
Ultra Librarian 3D Model Ultra Librarian MPX5050GP1 CAD Model

Description

The NXP MPX5050GP1 is a temperature-compensated sensor with a vented gauge pressure type.

  • Operating Pressure: 7.25 PSI (50 kPa)
  • Maximum Pressure: 29.01 PSI (200 kPa)
  • Output: analog voltage ranging from 0.2 V to 4.7 V with an accuracy of ±2.5%
  • Port Size: male 0.19" (4.93mm) tube
  • Port Style: barbed
  • Operating Temperature Range: -40°C to 125°C
  • Suitable for: use in transducers and sensors
