MPC8378EVRANGA Real Image
Same model may have multiple batches, images only for reference.

MPC8378EVRANGA

Part No MPC8378EVRANGA
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microprocessors
Description IC MPU MPC83XX 800MHZ 689TEBGA
Datasheet
MPC8378EVRANGA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tray
Status Active
Core Processor PowerPC e300c4s
Number of Cores/Bus Width 1 Core, 32-Bit
Speed(Frequency) 800MHz
Co-Processors/DSP Security; SEC 3.0
RAM Controllers DDR, DDR2
Graphics Acceleration No
Ethernet 10/100/1000 Mbps (2)
USB USB 2.0 + PHY (1)
Voltage - I/O 1.8V, 2.5V, 3.3V
Temperature Range - Operating 0°C to 125°C (TA)
Security Features Cryptography, Random Number Generator
Case / Package 689-TEPBGA II (31x31)
Additional Interfaces DUART, I2C, MMC/SD, PCI, SPI
Win Source Part Number 140036-MPC8378EVRANGA
Ultra Librarian 3D Model Ultra Librarian MPC8378EVRANGA CAD Model

Description

The NXP MPC8378EVRANGA is a PowerPC e300c4s core processor with 32-bit bus width.

  • RAM Controllers: DDR and DDR2 RAM controllers
  • Ethernet: 10/100/1000 Mbps Ethernet
  • USB: USB 2.0 + PHY
  • Additional Interfaces: DUART, I2C, MMC/SD, PCI, and SPI
  • Security: Security co-processor with cryptography and random number generator features
  • Speed: 800MHz
  • Voltage Range: 1.8V to 3.3V
  • Package: 689-TEPBGA II (31x31) case
  • Application: Suitable for use in integrated circuits
