MCIMX515DJM8C Real Image MCIMX515DJM8C real image MCIMX515DJM8C real image2834 MCIMX515DJM8C Real Image1 MCIMX515DJM8C Real Image2 MCIMX515DJM8C Real Image3 MCIMX515DJM8C Real Image4
Same model may have multiple batches, images only for reference.
MCIMX515DJM8C Real Image MCIMX515DJM8C real image MCIMX515DJM8C real image2834 MCIMX515DJM8C Real Image1 MCIMX515DJM8C Real Image2 MCIMX515DJM8C Real Image3 MCIMX515DJM8C Real Image4
MCIMX515DJM8C Real Image MCIMX515DJM8C real image MCIMX515DJM8C real image2834 MCIMX515DJM8C Real Image1 MCIMX515DJM8C Real Image2 MCIMX515DJM8C Real Image3 MCIMX515DJM8C Real Image4
Same model may have multiple batches, images only for reference.

MCIMX515DJM8C

Part No MCIMX515DJM8C
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microprocessors
Description SOC i.MX51 ARM Cortex A8 0.06um 529-Pin BGA Tray / IC MPU I.MX51 800MHZ 529BGA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tray
Status Active
Core Processor ARM Cortex-A8
Number of Cores/Bus Width 1 Core, 32-Bit
Speed(Frequency) 800MHz
Co-Processors/DSP Multimedia; NEON SIMD
RAM Controllers LPDDR, DDR2
Graphics Acceleration Yes
Display & Interface Controllers Keypad, LCD
Ethernet 10/100 Mbps (1)
USB USB 2.0 (3), USB 2.0 + PHY (1)
Voltage - I/O 1.2V, 1.875V, 2.775V, 3.0V
Temperature Range - Operating -20°C to 85°C (TC)
Security Features ARM TZ, Boot Security, Cryptography, RTIC, Secure Fusebox, Secure JTAG, Secure Memory, Secure RTC
Case / Package 529-BGA Case 2017 (19x19)
Additional Interfaces 1-Wire, AC'97, I2C, I2S, MMC/SD, SPI, SSI, UART
Win Source Part Number 017248-MCIMX515DJM8C
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MCIMX515
Introduction Date November 07, 2009
ECCN 5A992.c
Country of Origin China, Taiwan
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian MCIMX515DJM8C CAD Model

Description

The NXP MCIMX515DJM8C is an integrated circuit (IC) that is designed for embedded microcontrollers.

  • Package: Tray
  • Core Processor: ARM Cortex-A8
  • Cores/Bus Width: 1 core, 32-bit
  • Co-processors/DSP: Multimedia and NEON SIMD
  • RAM Controllers: LPDDR and DDR2
  • Graphics Acceleration: Yes
  • Display & Interface Controllers: Keypad and LCD
  • Ethernet: 10/100 Mbps (1)
  • USB: USB 2.0 (3), USB 2.0 + PHY (1)
  • Voltage - I/O: 1.2V, 1.875V, 2.775V, 3.0V
  • Security Features: ARM TZ, boot security, cryptography, RTIC, secure fusebox, secure JTAG, secure memory, and secure RTC
  • Interfaces: 1-Wire, AC'97, I2C, I2S, MMC/SD, SPI, SSI, and UART
  • Status: Active
  • Speed (Frequency): 800MHz
  • Supply and Demand Status: Balanced
