MC9S12XDP512MAL Real Image MC9S12XDP512MAL real image2823 MC9S12XDP512MAL Real Image1 MC9S12XDP512MAL Real Image2 MC9S12XDP512MAL Real Image3 MC9S12XDP512MAL Real Image4
Same model may have multiple batches, images only for reference.
MC9S12XDP512MAL Real Image MC9S12XDP512MAL real image2823 MC9S12XDP512MAL Real Image1 MC9S12XDP512MAL Real Image2 MC9S12XDP512MAL Real Image3 MC9S12XDP512MAL Real Image4
MC9S12XDP512MAL Real Image MC9S12XDP512MAL real image2823 MC9S12XDP512MAL Real Image1 MC9S12XDP512MAL Real Image2 MC9S12XDP512MAL Real Image3 MC9S12XDP512MAL Real Image4
Same model may have multiple batches, images only for reference.

MC9S12XDP512MAL

Part No MC9S12XDP512MAL
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microcontrollers
Description IC MCU 16BIT 512KB FLASH 112LQFP
Datasheet
MC9S12XDP512MAL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tray
Status Active
Core Processor HCS12X
Part Core Size 16-Bit
Speed(Frequency) 80MHz
Number of I/O 91
Program Memory Size 512KB (512K x 8)
Program Memory Type FLASH
EEPROM Size 4K x 8
Data RAM Size 32K x 8
Supply Voltage - Operating 2.35 V to 5.5 V
Data Converters A/D 16x10b
Oscillator Type External
Temperature Range - Operating -40°C to 125°C (TA)
Case / Package 112-LQFP (20x20)
Win Source Part Number 208132-MC9S12XDP512MAL
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MC9S12XDP512MAL CAD Model

Description

The NXP 208132-MC9S12XDP512MAL is an HCS12X core processor that comes with 91 I/O and 512KB (512K x 8) FLASH program memory.

  • EEPROM Size: 4K x 8
  • Data Converters: A/D 16x10b
  • Speed: 80MHz
  • Temperature Range: -40°C to 125°C (TA)
  • Data RAM Size: 32K x 8
  • Voltage Range: 2.35 V to 5.5 V
  • Suitable For: Integrated Circuits
  • Status: Active
  • Package: 112-LQFP (20x20)
  • Popularity: Medium
