MC9S08SH8CTGR

Name: MC9S08SH8CTGR
Brand: Freescale Semiconductor - NXP
SKU: 224956
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	MC9S08SH8CTGR
Manufacturer	Freescale Semiconductor - NXP
Catalog	Embedded - Microcontrollers
Description	IC MCU 8BIT 8KB FLASH 16TSSOP / MCU 8-bit S08 CISC 8KB Flash 3.3V/5V 16-Pin TSSOP T/R
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	NXP
Packaging	Reel - TR
Status	Active
Core Processor	S08
Part Core Size	8-Bit
Speed(Frequency)	40MHz
Number of I/O	13
Program Memory Size	8KB (8K x 8)
Program Memory Type	FLASH
Data RAM Size	512 x 8
Supply Voltage - Operating	2.7 V to 5.5 V
Data Converters	A/D 8x10b
Temperature Range - Operating	-40°C to 85°C (TA)
Case / Package	16-TSSOP
Win Source Part Number	022990-MC9S08SH8CTGR
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	MC9S08SH8
Introduction Date	March 01, 2008
ECCN	3A991.a.2
Country of Origin	China, Taiwan, United States of America
Halogen Free	Compliant
Estimated EOL Date	2028
Ultra Librarian 3D Model	Ultra Librarian MC9S08SH8CTGR CAD Model

Alternative Products

Description

The NXP 022990-MC9S08SH8CTGR is an active electronic component that is suitable for use in various integrated circuit applications.

Supply and Demand Status: balance
Temperature Range: -40°C to 85°C
Package: 16-TSSOP
