SS34 Fairchild/ON Semiconductor SS34 Real Image SS34 label picture SS34 label picture 2
Same model may have multiple batches, images only for reference.
SS34 Fairchild/ON Semiconductor SS34 Real Image SS34 label picture SS34 label picture 2
SS34 Fairchild/ON Semiconductor SS34 Real Image SS34 label picture SS34 label picture 2
Same model may have multiple batches, images only for reference.

SS34

Part No SS34
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 3A SMC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 40V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Maximum) @ If 500mV @ 3A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 500μA @ 40V
Mounting SMD
Package DO-214AB, SMC
Manufacturer Package SMC (DO-214AB)
Operating Temperature - Junction -55°C ~ 150°C
Win Source Part Number 095337-SS34
Family Name SS34
Introduction Date January 14, 2000
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian SS34 CAD Model

Description

The SS34 is a Schottky diode manufactured by Fairchild/ON Semiconductor.

  • Popularity: High
  • Supply and Demand Status: Sufficient
  • Forward Voltage: 500mV (maximum)
  • Reverse Voltage: 40V (maximum)
