NC7SZ32P5X

Name: NC7SZ32P5X
Brand: Fairchild/ON Semiconductor
SKU: 250120
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	NC7SZ32P5X
Manufacturer	Fairchild/ON Semiconductor
Catalog	Logic - Gates and Inverters
Description	OR Gate 1-Element 2-IN CMOS 5-Pin SC-70 T/R / IC GATE OR 1CH 2-INP SC-70-5
Datasheet	NC7SZ32P5X Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Logic Type	OR Gate
Number of Circuits	1
Number of Inputs	2
Supply Voltage - Operating	1.65 V to 5.5 V
Current - Quiescent (Max)	2μA
Current - Output High, Low	32mA, 32mA
Max Propagation Delay @ V, Max CL	4.5ns @ 5V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	SC-70-5
Dimension	5-TSSOP, SC-70-5, SOT-353
Win Source Part Number	024829-NC7SZ32P5X
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Quantity per package	3k pcs
Family Name	NC7SZ32
Introduction Date	December 15, 1997
ECCN	EAR99
Country of Origin	China, Malaysia, Philippines, Thailand
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian NC7SZ32P5X CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor NC7SZ32P5X is a single OR gate with two inputs and a maximum propagation delay of 4.5ns @ 5V and 50pF.

Quiescent Current: 2μA
Output Current: 32mA for both high and low
Logic Level for Low: Not specified
Logic Level for High: Not applicable
Family: NC7SZ32
Packaging: SC-70-5
Operating Temperature: -40°C to 85°C
Supply Voltage: 1.65 V to 5.5 V
Supply and Demand Status: Sufficient with 3k pcs per package
