NC7S04M5X Fairchild/ON Semiconductor NC7S04M5X Real Image NC7S04M5X label picture NC7S04M5X real image3852 NC7S04M5X Real Image1 NC7S04M5X Real Image2 NC7S04M5X Real Image3 NC7S04M5X Real Image4 NC7S04M5X Real Image5
Same model may have multiple batches, images only for reference.
NC7S04M5X Fairchild/ON Semiconductor NC7S04M5X Real Image NC7S04M5X label picture NC7S04M5X real image3852 NC7S04M5X Real Image1 NC7S04M5X Real Image2 NC7S04M5X Real Image3 NC7S04M5X Real Image4 NC7S04M5X Real Image5
NC7S04M5X Fairchild/ON Semiconductor NC7S04M5X Real Image NC7S04M5X label picture NC7S04M5X real image3852 NC7S04M5X Real Image1 NC7S04M5X Real Image2 NC7S04M5X Real Image3 NC7S04M5X Real Image4 NC7S04M5X Real Image5
Same model may have multiple batches, images only for reference.

NC7S04M5X

Part No NC7S04M5X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC INVERTER HS SINGLE SOT-23-5
Datasheet
NC7S04M5X Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 1
Number of Inputs 1
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 2.6mA, 2.6mA
Logic Level - Low 0.5V
Logic Level - High 1.5V
Max Propagation Delay @ V, Max CL 17ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Dimension SC-74A, SOT-753
Win Source Part Number 024729-NC7S04M5X
Family Name NC7S04
Introduction Date April 21, 2011
ECCN EAR99
Country of Origin China, Philippines
Halogen Free Compliant
Estimated EOL Date 2025
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Industrial
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7S04M5X CAD Model

Description

The Fairchild/ON Semiconductor 024729-NC7S04M5X is an inverter logic type integrated circuit.

  • Mounting: SOT-23-5 package
  • Input: Single
  • Current-Output High: 2.6mA
  • Max Propagation Delay @ V, Max CL: 17ns @ 6V, 50pF
  • Current-Quiescent (Max): 1μA
  • Logic Level-Low: 0.5V
  • Logic Level-High: 1.5V
  • Temperature Range: -40°C to 85°C
  • Supply Voltage-Operating: 2V to 6V
  • Applications: Power management and industrial
