MTD3055VL Real Image MTD3055VL Real Image1 MTD3055VL Real Image2 MTD3055VL Real Image3
MTD3055VL Real Image MTD3055VL Real Image1 MTD3055VL Real Image2 MTD3055VL Real Image3
Same model may have multiple batches, images only for reference.

MTD3055VL

Part No MTD3055VL
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 12A DPAK
Datasheet
MTD3055VL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 12A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 5V
Gate-Source Threshold Voltage 2V @ 250μA
Max Gate Charge 10nC @ 5V
Max Input Capacitance 570pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3.9W (Ta), 48W (Tc)
Maximum Rds On at Id,Vgs 180 mOhm @ 6A, 5V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252-3
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 024581-MTD3055VL
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Power Management
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian MTD3055VL CAD Model

Description

The MTD3055VL is an N-Channel MOSFET from Fairchild/ON Semiconductor. It comes in a TO-252-3 package and is designed for SMD (SMT) mounting.

  • Package: TO-252-3
  • Mounting Type: SMD (SMT)
  • Drain-Source Breakdown Voltage: 60V
  • Continuous Drain Current: 12A (Tc)
  • Gate-Source Threshold Voltage: 2V @ 250μA
  • Maximum Gate Charge: 10nC @ 5V
  • Maximum Input Capacitance: 570pF @ 25V
  • Maximum Rds On @ Id,Vgs: 180 mOhm @ 6A, 5V
  • Power Dissipation: 3.9W (Ta), 48W (Tc)
  • Suitable for Use in: Power management
  • Drive Voltage (Max Rds On, Min Rds On): 5V
  • Popularity: popular
  • Package Contains: 2,500 pcs
