MOC3063SR2M Real Image MOC3063SR2M real image3541
Same model may have multiple batches, images only for reference.
MOC3063SR2M Real Image MOC3063SR2M real image3541
MOC3063SR2M Real Image MOC3063SR2M real image3541
Same model may have multiple batches, images only for reference.

MOC3063SR2M

Part No MOC3063SR2M
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Triac, SCR Output
Description Triac AC-OUT 1-CH 600V 6-Pin PDIP SMD T/R / OPTOISOLATOR 4.17KV TRIAC 6SMD
Datasheet
MOC3063SR2M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Output Type Triac
Zero Crossing Circuit Yes
Number of Channels 1
Isolation Voltage 4170Vrms
Voltage - Off State 600V
Static dV/dt (Min) 600V/μs
Current - LED Trigger (Ift) (Max) 5mA
Current - Hold (Ih) 500μA (Typ)
Forward Voltage 1.3V
Continuous forward current- Max 60mA
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 6-SMD
Approvals UL
Win Source Part Number 024192-MOC3063SR2M
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 1k pcs
Family Name MOC3063M
Introduction Date May 29, 2003
ECCN EAR99
Country of Origin Singapore, Thailand
Halogen Free Not Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian MOC3063SR2M CAD Model

Description

The Fairchild/ON Semiconductor MOC3063SR2M is an isolator with a triac output type and a forward voltage of 1.3V.

  • Output Type: triac
  • Forward Voltage: 1.3V
  • Isolation Voltage: 4170Vrms
  • Static dV/dt: 600V/μs
  • Packaging: reel-TR
  • Case/Package: 6-SMD
  • Category: Isolators
  • Status: active
  • Continuous Forward Current-Max: 60mA
  • Current-Hold: 500μA (Typ)
  • Alternative Parts: VO3063-X007T, VO3062-X007T, MOC3063TM_NL, and MOC3063M_NL
