MM74HC08MX Real Image MM74HC08MX real image3329
Same model may have multiple batches, images only for reference.
MM74HC08MX Real Image MM74HC08MX real image3329
MM74HC08MX Real Image MM74HC08MX real image3329
Same model may have multiple batches, images only for reference.

MM74HC08MX

Part No MM74HC08MX
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC GATE AND 4CH 2-INP 14-SOIC
Datasheet
MM74HC08MX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type AND Gate
Number of Circuits 4
Number of Inputs 2
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 5.2mA, 5.2mA
Logic Level - Low 0.5 V to 1.8 V
Logic Level - High 1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL 20ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 023591-MM74HC08MX
Popularity Medium
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian MM74HC08MX CAD Model

Description

The 023591-MM74HC08MX from Fairchild/ON Semiconductor is a 4-circuit AND gate with SMD (SMT) mounting.

  • Logic Type: AND gate
  • Number of Inputs: 2
  • Current-Output High: 5.2mA
  • Current-Output Low: 5.2mA
  • Maximum Propagation Delay: 20ns @ 6V, 50pF
  • Logic Level-Low: 0.5V to 1.8V
  • Logic Level-High: 1.5V to 4.2V
  • Temperature Range: -40°C to 85°C
  • Supply Voltage: 2V to 6V
