HCPL2601SD Real Image HCPL2601SD Real Image
Same model may have multiple batches, images only for reference.
HCPL2601SD Real Image HCPL2601SD Real Image
HCPL2601SD Real Image HCPL2601SD Real Image
Same model may have multiple batches, images only for reference.

HCPL2601SD

Part No HCPL2601SD
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Logic Output
Description OPTOISO 2.5KV OPN COLLECTOR 8SMD
Datasheet
HCPL2601SD Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 5kV/μs
Input Type DC
Output Type Open Collector
Channel Output Current 50mA
Data Rate 10Mbps
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Rise and Fall Time 50ns, 12ns
Forward Voltage 1.4V
Continuous forward current- Max 50mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SMD
Win Source Part Number 1042617-HCPL2601SD
Popularity Medium
Supply and Demand Status Balance
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian HCPL2601SD CAD Model

Description

The HCPL2601SD is a high-speed optocoupler manufactured by Fairchild/ON Semiconductor.

  • Package: 8-SMD
  • Data Rate: 10Mbps
  • Output Type: Open collector
  • Input Type: DC
  • Common Mode Transient Immunity: 5kV/μs
  • Propagation Delay: 75ns, 75ns (tpLH/tpHL max)
  • Isolation Voltage: 2500Vrms
  • Operating Temperature: -40°C to 85°C
  • Channel Output Current: 50mA
  • Continuous Forward Current: 50mA
