H11L1M Real Image H11L1M real image4506
Same model may have multiple batches, images only for reference.
H11L1M Real Image H11L1M real image4506
H11L1M Real Image H11L1M real image4506
Same model may have multiple batches, images only for reference.

H11L1M

Part No H11L1M
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Logic Output
Description OPTOISO 4.17KV OPN COLL 6DIP
Datasheet
H11L1M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 4170Vrms
Input Type DC
Output Type Open Collector
Channel Output Current 50mA
Data Rate 1MHz
Propagation Delay tpLH / tpHL (Max) 4μs, 4μs
Rise and Fall Time 100ns, 100ns
Forward Voltage 1.2V
Continuous forward current- Max 30mA
Supply Voltage - Operating 3 V to 15 V
Temperature Range - Operating -40°C to 85°C
Mounting Through Hole
Case / Package 6-DIP
Win Source Part Number 001456-H11L1M
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Industrial
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian H11L1M CAD Model

Description

The Fairchild/ON Semiconductor 001456-H11L1M is an open collector output type isolator designed for high efficiency and reliability.

  • Response Time: 7μs, 45μs
  • Rise and Fall Time: 100ns
  • Isolation Voltage: 4170Vrms
  • Package: 6-DIP
  • Applications: Power Management and Industrial
  • Manufacturer: Fairchild/ON Semiconductor
  • Part Number: 001456-H11L1M
