H11A817B Real Image H11A817B Real Image1 H11A817B Real Image2
Same model may have multiple batches, images only for reference.
H11A817B Real Image H11A817B Real Image1 H11A817B Real Image2
H11A817B Real Image H11A817B Real Image1 H11A817B Real Image2
Same model may have multiple batches, images only for reference.

H11A817B

Part No H11A817B
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 5.3KV TRANSISTOR 4DIP
Datasheet
H11A817B Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Obsolete(EOL)
Number of Channels 1
Isolation Voltage 5300Vrms
Minimum DC Current Transfer Ratio 130% @ 5mA
Maximum DC Current Transfer Ratio 260% @ 5mA
Rise and Fall Time 2.4μs, 2.4μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 70V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 200mV
Temperature Range - Operating -55°C to 100°C
Mounting Through Hole
Case / Package 4-DIP
Win Source Part Number 001437-H11A817B
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian H11A817B CAD Model

Description

The H11A817B is a through-hole optocoupler from Fairchild/ON Semiconductor designed for DC input applications.

  • Minimum DC Current Transfer Ratio: 130%
  • Maximum DC Current Transfer Ratio: 260%
  • Maximum Output Voltage: 70V
  • Channel Output Current: 50mA
  • Package: 4-DIP
  • Temperature Range: -55°C to 100°C
  • Supply and Demand Status: Balanced
  • Status: Obsolete (EOL)
