FSGM0765RLDTU

Part No FSGM0765RLDTU
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SW FLBACK TO220F-6L / Converter Offline Flyback Topology 66kHz TO-220F-6L (L-Forming)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - AC DC Converters, Offline Switchers
Mfr Fairchild Semiconductor
Series FPS™
Package Bulk
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 650V
Topology Flyback
Voltage - Start Up 12 V
Supply Voltage - Operating 7.5V ~ 26V
Duty Cycle 70%
Frequency - Switching 66kHz
Power (Watts) 90 W
Fault Protection Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit
Temperature Range - Operating -40°C ~ 125°C (TJ)
Package / Case TO-220-6 Full Pack, Formed Leads
Supplier Device Package TO-220F-6L (L-Forming)
Mounting Type Through Hole
ECCN EAR99
HTSUS 8542.39.0001
Other Names FAIFSCFSGM0765RLDTU,2156-FSGM0765RLDTU
Standard Package 1
Win Source Part Number 999642-FSGM0765RLDTU
Ultra Librarian 3D Model Ultra Librarian FSGM0765RLDTU CAD Model

Description

The FSGM0765RLDTU is an Integrated Circuit (IC) from the FPS™ series of Fairchild Semiconductor.

  • Component Category: PMIC - AC DC Converters, Offline Switchers
  • Package: TO-220-6 full pack, formed leads
  • Power: 90W
  • Isolation: Isolated
  • Internal Switch: Yes
  • Breakdown Voltage: 650V
  • Topology: Flyback
  • Start-Up Voltage: 12V
  • Duty Cycle: 70%
  • Switching Frequency: 66kHz
  • Fault Protection: Current limiting, over load, over temperature, over voltage, and short circuit
  • Operating Temperature Range: -40°C to 125°C (TJ)
  • Supply Voltage Operating Range: 7.5V to 26V
