FGA25N120ANTD Fairchild/ON Semiconductor FGA25N120ANTD real image4174
Same model may have multiple batches, images only for reference.
FGA25N120ANTD Fairchild/ON Semiconductor FGA25N120ANTD real image4174
FGA25N120ANTD Fairchild/ON Semiconductor FGA25N120ANTD real image4174
Same model may have multiple batches, images only for reference.

FGA25N120ANTD

Part No FGA25N120ANTD
Manufacturer Fairchild/ON Semiconductor
Catalog IGBTs - Single
Description Trans IGBT Chip N-CH 1200V 50A 312000mW 3-Pin(3+Tab) TO-3PN / IGBT 1200V 50A 312W TO3P
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
IGBT Type NPT and Trench
VCEO Maximum Collector-Emitter Breakdown Voltage 1200V
Maximum Current Collector 50A
Pulsed Collector Current 90A
Collector-emitter saturation voltage(Max) 2.65V @ 15V, 50A
Maximum Power Dissipation 312W
Total Switching Energy(Ets) 4.1mJ (on), 960μJ (off)
Input Type Standard
Gate Charge 200nC
Turn-on and Turn-off delay time 50ns/190ns
Testing Conditions 600V, 25A, 10 Ohm, 15V
Reverse Recovery Time (trr) 350ns
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-3P
Win Source Part Number 089796-FGA25N120ANTD
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name FGA25N120ANTD
Introduction Date September 14, 2004
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian FGA25N120ANTD CAD Model

Description

The FGA25N120ANTD is an IGBT transistor manufactured by Fairchild/ON Semiconductor.

  • Packaging: Tube/Rail
  • Mounting Type: Through Hole
  • IGBT Type: NPT and Trench
  • Input Type: Standard
  • Gate Charge: 200nC
  • Supply and Demand: Limited
  • Maximum Current Collector: 50A
  • VCEO Maximum Collector-Emitter Breakdown Voltage: 1200V
  • Maximum Power Dissipation: 312W
  • Pulsed Collector Current: 90A
  • Collector-Emitter Saturation Voltage (Max): 2.65V @ 15V, 50A
  • Total Switching Energy (Ets): 4.1mJ (on), 960μJ (off)
  • Turn-On/Turn-Off Delay Time: 50ns / 190ns
  • Testing Conditions: 600V, 25A, 10 Ohm, 15V
  • ECCN: EAR99
  • EOL Status: Obsolete/End of Life
