9595293202 FAIR-RITE PRODUCTS – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

9595293202

Part No 9595293202
Manufacturer FAIR-RITE PRODUCTS
Catalog Ferrite Cores
Description FERRITE CORE ETD 95 SET
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Core Type ETD
Material 95
Tolerance ±25%
Gap Ungapped
Initial Permeability (µi) 3000
Core Factor (ΣI/A) mm⁻¹ 95.0
Effective Length (le) mm 70.7
Effective Area (Ae) mm2 76.7
Minimum Core Cross Section (Amin) mm2 70.9
Effective Magnetic Volume (Ve) mm3 5418.0
Finish Uncoated
Height 0.622" (15.80mm)
Width 0.374\
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1528167-9595293202
Ultra Librarian 3D Model Ultra Librarian 9595293202 CAD Model
