9595283402 FAIR-RITE PRODUCTS – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

9595283402

Part No 9595283402
Manufacturer FAIR-RITE PRODUCTS
Catalog Ferrite Cores
Description FERRITE CORE EER 95 SET
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Core Type EER
Material 95
Tolerance ±25%
Gap Ungapped
Initial Permeability (µi) 3000
Core Factor (ΣI/A) mm⁻¹ 87.0
Effective Length (le) mm 74.4
Effective Area (Ae) mm2 85.2
Minimum Core Cross Section (Amin) mm2 77.0
Effective Magnetic Volume (Ve) mm3 6337.0
Finish Uncoated
Length 1.122" (28.50mm)
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1528166-9595283402
Ultra Librarian 3D Model Ultra Librarian 9595283402 CAD Model

Description

N
