The FZ1200R17KE3 is an IGBT module manufactured by eupec GmbH (now Infineon Technologies). This module is designed for high-power switching applications. It contains two IGBTs (Insulated Gate Bipolar Transistors) in a half-bridge configuration, making it suitable for inverter designs and other power electronics applications.

Applications

• Motor drives: Used in AC and DC motor drives for controlling the speed and torque of electric motors.
• Inverters: Employed in solar inverters, UPS (Uninterruptible Power Supplies), and frequency inverters to convert DC power to AC power.
• Welding machines: Utilized in welding equipment for controlling the welding current and voltage.
• Power supplies: Used in high-power SMPS (Switched-Mode Power Supplies) for various industrial and commercial applications.
• Traction: Found in electric trains, trams, and other electric vehicles.

Features

• High current capability: Designed to handle high current loads up to 1200A.
• High voltage rating: Rated for voltages up to 1700V.
• Half-bridge configuration: Contains two IGBTs in a half-bridge configuration.
• Low switching losses: Optimizes efficiency in high-frequency switching applications.
• Integrated temperature sensor: Provides temperature monitoring for protection and control.
• Robust design: Designed for reliable operation in harsh industrial environments.

Benefits

• Increased efficiency: Low switching losses contribute to higher overall system efficiency.
• Improved reliability: Robust design ensures reliable operation in demanding applications.
• Simplified design: Half-bridge configuration simplifies inverter designs.
• Enhanced protection: Integrated temperature sensor enables over-temperature protection.
• High power density: Compact module design allows for high power density.

Additional Details

The FZ1200R17KE3 IGBT module features a collector-emitter voltage (Vces) of 1700V and a continuous collector current (Ic) of 1200A. It has a typical turn-on delay time of 150 ns and a typical turn-off delay time of 450 ns. The module includes an integrated NTC thermistor for temperature sensing. It is typically mounted on a heatsink to dissipate heat generated during operation. The module package is a standard industry package that allows for easy mounting and connection. The operating junction temperature range is typically from -40°C to +150°C.
