S20K275E2 EPCOS (TDK) S20K275E2 Real Image S20K275E2 label picture S20K275E2 real image 2
Same model may have multiple batches, images only for reference.
S20K275E2 EPCOS (TDK) S20K275E2 Real Image S20K275E2 label picture S20K275E2 real image 2
S20K275E2 EPCOS (TDK) S20K275E2 Real Image S20K275E2 label picture S20K275E2 real image 2
Same model may have multiple batches, images only for reference.

S20K275E2

Part No S20K275E2
Manufacturer EPCOS (TDK)
Catalog TVS - Varistors, MOVs
Description VARISTOR 430V 10KA DISC 20MM
Datasheet
S20K275E2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer EPCOS (TDK)
Packaging Bulk
Status Active
Varistor Voltage (Min) 387V
Varistor Voltage (Typ) 430V
Varistor Voltage (Max) 473V
Current - Surge 10kA
Energy 215J
Number of Circuits 1
Maximum AC Volts 275VAC
Maximum DC Volts 350VDC
Capacitance @ Frequency 850pF @ 1kHz
Temperature Range - Operating -40°C to 85°C (TA)
Mounting Through Hole
Dimension Disc 20mm
Win Source Part Number 211156-S20K275E2
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian S20K275E2 CAD Model

Description

The EPCOS (TDK) 211156-S20K275E2 is a circuit protection component with a capacitance of 850pF @ 1kHz.

  • Capacitance: 850pF @ 1kHz
  • Varistor Voltage (Min): 387V
  • Varistor Voltage (Typ): 430V
  • Varistor Voltage (Max): 473V
  • Maximum AC Volts: 275VAC
  • Maximum DC Volts: 350VDC
  • Surge Current: 10kA
  • Energy: 215J
  • Popularity: high popularity
  • Supply and Demand Status: balanced
  • Risk of fake components: high risk of fake components in the open market, which is at 78 percent.
