B82801A0824A100 EPCOS (TDK)
Same model may have multiple batches, images only for reference.

B82801A0824A100

Part No B82801A0824A100
Manufacturer EPCOS (TDK)
Catalog Current Sense Transformers
Description Current Transformer 1:100 500VAC 0.0025Ohm Prim. DCR 8.7Ohm Sec. DCR 820uH Prim. 7000mA Prim. 4 Terminal SMD / TRANSF CURRENT SENSE 820UH SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Transformers
Manufacturer EPCOS (TDK)
Packaging Reel - TR
Status Active
Frequency Range 50kHz to 1MHz
Type Invasive
Inductance 820μH
DC Resistance (DCR) 2.5 mOhm Primary, 8.7 Ohm Secondary
Mounting SMD (SMT)
Height - Seated (Max) 0.138" (3.50mm)
Termination Style J Lead
Weight 0.006 oz (0.17g)
Win Source Part Number 039537-B82801A0824A100
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name B82801A
Introduction Date January 27, 1999
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian B82801A0824A100 CAD Model

Description

Overview

The B82801A0824A100 is engineered to provide high efficiency in electrical circuits, ensuring seamless performance in crucial applications.

Features and Benefits

  • Exceptional electrical efficiency
  • Durable construction for long-term use
  • Compatible with a broad range of voltages

Applications

  • Automotive electronics
  • Renewable energy systems
  • Aerospace applications

Additional Details

Suitable for environments where reliability and efficiency are paramount, this component is perfect for cutting-edge technology projects.
