B82793C474N215 EPCOS (TDK) B82793C474N215 Real Image B82793C474N215 label picture
Same model may have multiple batches, images only for reference.
B82793C474N215 EPCOS (TDK) B82793C474N215 Real Image B82793C474N215 label picture
B82793C474N215 EPCOS (TDK) B82793C474N215 Real Image B82793C474N215 label picture
Same model may have multiple batches, images only for reference.

B82793C474N215

Part No B82793C474N215
Manufacturer EPCOS (TDK)
Catalog Common Mode Chokes
Description Common Mode Choke Surface Mount Signal Line 700mA 2 Lines 170 mOhm (Typ) -40°C ~ 125°C
Datasheet
B82793C474N215 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters
Family Common Mode Chokes
Manufacturer EPCOS (TDK)
Series B82793
Packaging Reel(TR)
Filter Type Signal Line
Number of Lines 2
Inductance @ Frequency 470μH @ 100kHz
Current Rating (Max) 700mA
DC Resistance (DCR) (Max) 170 mOhm (Typ)
Voltage Rating - DC 80V
Voltage Rating - AC 42V
Operating Temperature Range -40°C ~ 125°C
Ratings AEC-Q200
Mounting Style SMD/SMT
Size / Dimension 0.280" L x 0.236" W (7.10mm x 6.00mm)
Height (Max) 0.189" (4.80mm)
Package Horizontal, 4 Gull Wing
Win Source Part Number 010702-B82793C474N215
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name B82793C0
Introduction Date January 27, 1999
ECCN EAR99
Country of Origin China
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian B82793C474N215 CAD Model

Description

Description

The B82793C474N215 is tailored to provide comprehensive electromagnetic interference management, enhancing the performance of sensitive electronic hardware. Ideal for critical applications, it ensures reliability and efficiency.

Features and Benefits

  • Robust EMI Management: Exceptional at curbing electromagnetic interference.
  • High Efficiency: Maximizes performance with minimal impact on size.
  • Reliable Operation: Maintains consistent performance under various conditions.
  • Developer Friendly: Simple installation and integration into existing systems.

Applications

  • Military Grade Equipment
  • Advanced Robotics
  • Smart Grid Technologies
  • Audio-Visual Equipment

Additional Details

The B82793C474N215 is constructed using advanced materials and innovative technologies, making it a leading choice for demanding environments where electromagnetic interference poses a significant concern.
