ECS-73-20-5PXDN-TR Real Image
Same model may have multiple batches, images only for reference.

ECS-73-20-5PXDN-TR

Part No ECS-73-20-5PXDN-TR
Manufacturer ECS Inc.
Catalog Oscillators
Description CRYSTAL 7.3728MHZ 20PF SMD / 7.3728 MHz ±30ppm Crystal 20pF 60 Ohms HC-49/US
Datasheet
ECS-73-20-5PXDN-TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators>Crystals
Manufacturer ECS Inc.
Packaging Reel - TR
Type MHz Crystal
Frequency 7.3728 MHz
Frequency Stability ±100ppm
Frequency Tolerance ±30ppm
Load Capacitance 20pF
ESR (Equivalent Series Resistance) 60 Ohms
Operating Mode Fundamental
Temperature Range - Operating -40°C ~ 85°C
Mounting Surface Mount
Case / Package HC-49/US
Size / Dimension 0.449" L x 0.189" W (11.40mm x 4.80mm)
Height - Seated (Max) 0.169" (4.30mm)
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.60.0050
Other Part Number Q3554841C,XC1296TR,XC1296DKR,XC1296CT,ECS73205PXDNTR
Standard Package 1,000
Win Source Part Number 1328366-ECS-73-20-5PXDN-TR
Ultra Librarian 3D Model Ultra Librarian ECS-73-20-5PXDN-TR CAD Model

Description

The 1328366-ECS-73-20-5PXDN-TR from ECS Inc. is a surface mount MHz crystal with a frequency of 7.3728 MHz and a load capacitance of 20pF.

  • Operating Mode: Fundamental
  • Frequency Tolerance: ±30ppm
  • Frequency Stability: ±100ppm
  • Height: 0.169" (4.30mm)
  • Size: 0.449" L x 0.189" W (11.40mm x 4.80mm)
  • ESR: 60 Ohms
  • Case: HC-49/US
  • Units per Reel: 1000
  • Operating Temperature: -40°C to 85°C
  • ROHS3 Compliant: Yes
