ECS-80-20-5PXDU-TR ECS Inc.
Same model may have multiple batches, images only for reference.

ECS-80-20-5PXDU-TR

Part No ECS-80-20-5PXDU-TR
Manufacturer ECS Inc.
Catalog Oscillators
Description CRYSTAL 8.0000MHZ 20PF SMD / 8 MHz ±30ppm Crystal 20pF 60 Ohms HC-49/US
Datasheet
ECS-80-20-5PXDU-TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators - Crystals
Mfr ECS Inc.
Series CSM-7X-DU
Package Tape & Reel
Product Status Active
Type MHz Crystal
Frequency 8 MHz
Frequency Stability ±100ppm
Frequency Tolerance ±30ppm
Load Capacitance 20pF
ESR (Equivalent Series Resistance) 60 Ohms
Operating Mode Fundamental
Temperature Range - Operating -55°C ~ 125°C
Ratings -
Mounting Type Surface Mount
Package / Case HC-49/US
Size / Dimension 0.449" L x 0.189" W (11.40mm x 4.80mm)
Height - Seated (Max) 0.169" (4.30mm)
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.60.0050
Win Source Part Number 1355589-ECS-80-20-5PXDU-TR
Ultra Librarian 3D Model Ultra Librarian ECS-80-20-5PXDU-TR CAD Model

Description

The ECS-80-20-5PXDU-TR is an 8 MHz crystal from ECS Inc.

  • Frequency: 8 MHz
  • Series: CSM-7X-DU
  • Mounting Type: Surface Mount
  • Size: 0.449" L x 0.189" W (11.40mm x 4.80mm)
  • Height: 0.169" (4.30mm)
  • ESR: 60 Ohms
  • Frequency Stability: ±100ppm
  • Frequency Tolerance: ±30ppm
  • Load Capacitance: 20pF
  • Temperature Range: -55°C to 125°C
  • Packaging: Tape & Reel
