FWP-90B Real Image
Same model may have multiple batches, images only for reference.

FWP-90B

Part No FWP-90B
Manufacturer Eaton Bussmann
Catalog Electrical, Specialty Fuses
Description FUSE CARTRIDGE 90A 700VAC/500VDC / 90A 700 V AC 500 V DC Fuse Cartridge Bolt Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Electrical, Specialty Fuses
Mfr Eaton - Bussmann Electrical Division
Series FWP
Package Bulk
Mounting Type Bolt Mount
Fuse Type Cartridge
Current Rating (Amps) 90A
Voltage Rating - AC 700 V
Voltage Rating - DC 500 V
Applications Electrical, Industrial
Approval Agency CE, CSA, UR
Breaking Capacity @ Rated Voltage 200kA AC, 50kA DC
Package / Case Cylindrical, Blade Terminal (Bolt)
Dimension 0.947" Dia x 2.594" L (24.05mm x 65.89mm)
Melting I2t 415
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.10.0040
Standard Package 10
Win Source Part Number 1104725-FWP-90B
Ultra Librarian 3D Model Ultra Librarian FWP-90B CAD Model

Description

The FWP series cartridge fuse from Eaton is a cylindrical, blade terminal (bolt) package that offers circuit protection for electrical and industrial applications.

  • Series: FWP
  • Fuse Type: cartridge
  • Voltage Rating (AC): 700V AC
  • Voltage Rating (DC): 500V DC
  • Breaking Capacity (AC): 200kA AC
  • Breaking Capacity (DC): 50kA DC
  • Response Time: Not specified
  • Current Rating: 90A
  • Melting I2t: 415
  • Package: bulk
  • Mounting Type: bolt mount
  • Dimensions: 0.947" Dia x 2.594" L (24.05mm x 65.89mm)
