170M3473 Real Image
Same model may have multiple batches, images only for reference.

170M3473

Part No 170M3473
Manufacturer Eaton Bussmann
Catalog Electrical, Specialty Fuses
Description FUSE SQUARE 630A 700VAC RECT / 630A 700 V AC DC Fuse Square Holder
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Electrical, Specialty Fuses
Mfr Eaton - Bussmann Electrical Division
Package Bulk
Mounting Type Holder
Fuse Type Square
Current Rating (Amps) 630A
Voltage Rating - AC 700 V
Applications Electrical, Industrial
Features Indicating
Approval Agency CSA, UR
Breaking Capacity @ Rated Voltage 200kA
Package / Case Rectangular, Blade
Dimension 2.323" L x 1.772" W x 2.008" H (59.00mm x 45.00mm x 51.00mm)
Melting I2t 48500
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.10.0040
Standard Package 6
Win Source Part Number 1078732-170M3473
Ultra Librarian 3D Model Ultra Librarian 170M3473 CAD Model

Description

The Eaton Bussmann Electrical Division circuit protection electrical specialty fuse is a square indicating fuse with a voltage rating of 700 V AC and a breaking capacity of 200kA @ rated voltage.

  • Indicating: Square
  • Voltage Rating: 700 V AC
  • Breaking Capacity @ Rated Voltage: 200kA
  • Melting I2t: 48500
  • Package: Rectangular blade
  • Current Rating: 630A
  • Package: Bulk
  • Standard Package: 6
  • Dimensions: 2.323" L x 1.772" W x 2.008" H (59.00mm x 45.00mm x 51.00mm)
  • Fuse Type: Square
  • Mounting: Holder
  • Approvals: CSA and UR
