Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Switches - DIP Switches
Mfr E-Switch
Series SRJ
Package Tube
Product Status Active
Circuit BCD
Number of Positions 10
Current Rating (Amps) 100mA
Voltage Rating 5VDC
Actuator Type Rotary for Tool
Actuator Level Flush, Recessed
Contact Material Glass Fabric Epoxy Resin
Contact Finish Gold
Height Above Board 0.256" (6.50mm)
Mounting Type Through Hole
Termination Style PC Pin
Pitch 0.100" (2.54mm), Full
Washable Yes
Temperature Range - Operating -10°C ~ 60°C
Body Material Polyphenylene Sulfide (PPS)
Length 0.394" (10.00mm)
Electrical Life 15,000 Cycles
Base Product Number SRJ
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9020
Win Source Part Number 676078-SRJ-10
Ultra Librarian 3D Model Ultra Librarian SRJ-10 CAD Model

Description

The SRJ-10 is a 10-position DIP switch from E-Switch.

  • Pitch: 0.100" (2.54mm)
  • Package: Tube
  • Circuit: BCD
  • Material: Polyphenylene Sulfide (PPS)
  • Voltage Rating: 5VDC
  • Current Rating: 100mA
  • Height Above Board: 0.256" (6.50mm)
  • Length: 0.394" (10.00mm)
  • Contact Finish: Gold
  • Washable Design: Yes
