The MPTCFG-V-T/R is a tactile switch manufactured by Diptronics. It's designed for surface mount applications and provides a momentary contact when pressed. This switch is commonly used in various electronic devices for user input and control.

Applications

• Consumer electronics: Used in remote controls, gaming consoles, and audio equipment.
• Industrial equipment: Implemented in control panels, testing equipment, and measurement devices.
• Medical devices: Employed in medical instruments and diagnostic equipment.
• Computer peripherals: Utilized in keyboards, mice, and other input devices.
• Automotive electronics: Found in car audio systems and dashboard controls.

Features

• Surface Mount Technology (SMT): Designed for automated assembly processes.
• Compact Size: Small form factor for space-constrained applications.
• Tactile Feedback: Provides a distinct click sensation for user confirmation.
• Momentary Contact: Switch activates only when pressed.
• High Reliability: Durable construction for long-lasting performance.

Benefits

• Easy Integration: SMT design simplifies assembly and reduces manufacturing costs.
• Space Saving: Compact size allows for dense circuit board layouts.
• User-Friendly: Tactile feedback enhances user experience.
• Reliable Performance: Ensures consistent and dependable operation.
• Versatile Applications: Suitable for a wide range of electronic devices.

Specifications

The MPTCFG-V-T/R tactile switch has a typical operating force range of 160gf to 260gf. It is designed for reflow soldering processes. The operating temperature range is typically -25°C to +70°C. The electrical life is rated for 100,000 cycles. The dimensions are typically 6.0mm x 6.0mm x 5.0mm. It is packaged in tape and reel for automated assembly.

This tactile switch provides a reliable and user-friendly input solution for various electronic devices. Its compact size, surface mount design, and tactile feedback make it an excellent choice for modern electronic applications. The durable construction ensures long-lasting performance and consistent operation.
