KBPC601 Real Image
Same model may have multiple batches, images only for reference.

KBPC601

Part No KBPC601
Manufacturer DIOTEC Electronics Corporation
Catalog Bridge Rectifiers
Description 1PH BRIDGE KBPC 100V 6A
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr DIOTEC Electronics Corporation
Package Box
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 100 V
Current - Average Rectified (Io) 3.8 A
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 3 A
Current - Reverse Leakage @ Vr 5 µA @ 100 V
Temperature Range - Operating -50°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case 4-Square, KBPC-6
Supplier Device Package KBPC6
Standard Package 200 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
HTSUS 8541.10.0000
Win Source Part Number 610027-KBPC601
Ultra Librarian 3D Model Ultra Librarian KBPC601 CAD Model

Description

The 610027-KBPC601 is a single-phase bridge rectifier diode with a maximum voltage rating of 100V.

  • Average Rectified Current: 3.8A
  • Forward Voltage Drop: 1.2V @ 3A
  • Reverse Leakage Current: 5μA @ 100V
  • Temperature Range: -50°C to 150°C
  • Mounting: Designed for through-hole mounting
  • Package: 4-Square KBPC-6 package
  • Standard Package: 200 pieces
  • Manufacturer: DIOTEC Electronics Corporation
  • Status: Active product
